Mô hình NO.: | ZD-GALWIRE | Ứng dụng: | Dây thừng, Bao bì, Lưới, Sản xuất, Hàng rào, Xây dựng |
---|---|---|---|
Hợp kim hay không: | Được làm theo yêu cầu | Tiêu chuẩn: | BS, JIS, GB, ASTM, DIN, AISI |
Vật liệu: | ASTM A36 A572 A992 S235jr/J0/J2 S355jr/J0/J2 | Được làm theo yêu cầu: | Vâng |
Chu kỳ tùy chỉnh: | 7-15 ngày | Tên sản phẩm: | dây thép mạ kẽm |
Thời hạn thanh toán: | Trả trước 30% T/T + Số dư 70% | MOQ: | 3 tấn |
chiều dài: | Được làm theo yêu cầu | Ưu điểm: | Chống mài mòn, khả năng gia công, hàn dễ dàng |
Thông số kỹ thuật2: | Zd-Galwire5 6 7 8 9 10 | Đặc điểm kỹ thuật3: | Zd-Galwire12 14 15 16 18 |
tiêu chuẩn1: | ASTM a 6/a 6m-07 BS 4-1:1993 En 10024 JIS G 3192 | Gói vận chuyển: | Gói tiêu chuẩn xuất khẩu/theo yêu cầu |
Thông số kỹ thuật: | Theo yêu cầu của khách hàng | Thương hiệu: | TRỊNH Đức |
Nguồn gốc: | Trung Quốc | Mã Hs: | 7217200000 |
Khả năng cung cấp: | 50000 tấn / tháng | ||
Làm nổi bật: | dây thép kẽm 0,7mm,dây thép galvanized 0 |
ZHENGDE Galvanized wire production process: It is processed by high-quality low-carbon steel wire rod, and the high-quality low-carbon steel is processed by drawing forming, pickling and derusting, high-temperature annealing, hot-dip galvanizing and cooling.
Galvanized wire characteristics: Galvanized iron wire has good toughness and elasticity, and the highest amount of zinc can reach 300 grams per square meter. It has the characteristics of thick galvanized layer and strong corrosion resistance.
Galvanized wire application: The products are widely used in various fields such as construction, handicrafts, weaving wire mesh, highway guardrails, product packaging and daily civilian use.
Galvanized wire is further divided into hot-dip galvanized wire and cold-dip galvanized wire (electro-galvanized wire), which are distinguished as follows:
Hot-dip galvanizing is dip-plating in a heated and melted zinc solution. The production speed is fast, and the coating is thick but uneven. The minimum thickness allowed by the market is 45 microns, and the maximum thickness can reach more than 300 microns. The color is darker, consumes more zinc metal, forms an infiltration layer with the base metal, and has good corrosion resistance. Hot-dip galvanizing can last for decades in outdoor environments.
Cold galvanizing (electrogalvanizing) is to gradually coat the metal surface with zinc through the unidirectional current in the electroplating tank. The production speed is slow, the coating is uniform, and the thickness is thin, usually only 3-15 microns. The appearance is bright and the corrosion resistance is poor. It usually rusts in a few months.
Compared with hot-dip galvanizing, the production cost of electro-galvanizing is lower.
Gauge | SWG | BWG | AWG | Metric system | ||||
in | mm | in | mm | in | mm | mm | kg/km | |
0 | 0.324 | 8.23 | ||||||
1 | 0.3 | 7.02 | ||||||
2 | 0.276 | 7.01 | ||||||
3 | 0.252 | 6.401 | 0.259 | 6.58 | 0.2294 | 5.83 | ||
4 | 0.232 | 5.893 | 0.238 | 6.05 | 0.2043 | 5.19 | 6 | 220 |
5 | 0.212 | 5.385 | 0.22 | 5.59 | 0.1819 | 4.62 | 5.5 | 185 |
6 | 0.192 | 4.811 | 0.203 | 5.16 | 0.162 | 4.11 | 5 | 153 |
7 | 0.176 | 4.47 | 0.18 | 4.57 | 0.1443 | 3.67 | 4.5 | 124 |
8 | 0.16 | 4.064 | 0.165 | 4.19 | 0.1285 | 3.26 | 4 | 98 |
9 | 0.144 | 3.658 | 0.148 | 3.76 | 0.1144 | 2.91 | 3.5 | 95 |
10 | 0.128 | 3.251 | 0.134 | 3.4 | 0.1019 | 2.59 | 3.2 | 62 |
11 | 0.116 | 2.946 | 0.12 | 3.05 | 0.09074 | 2.3 | 2.9 | 51 |
12 | 0.104 | 2.642 | 0.109 | 2.77 | 0.08081 | 2.05 | 2.6 | 41 |
13 | 0.092 | 2.337 | 0.095 | 2.41 | 0.07196 | 1.83 | 2.3 | 32 |
14 | 0.08 | 2.032 | 0.083 | 2.11 | 0.06408 | 1.63 | 2 | 24 |
15 | 0.072 | 1.829 | 0.072 | 1.83 | 0.05707 | 1.45 | 1.8 | 20 |
16 | 0.064 | 1.626 | 0.065 | 1.65 | 0.05082 | 1.29 | 1.6 | 16 |
17 | 0.056 | 1.422 | 0.058 | 1.47 | 0.04526 | 1.15 | 1.4 | 12 |
18 | 0.048 | 1.219 | 0.049 | 1.24 | 0.0403 | 1.02 | 1.2 | 8 |
19 | 0.04 | 1.016 | 0.042 | 1.07 | 0.03589 | 0.91 | 1 | 6 |
20 | 0.036 | 0.914 | 0.035 | 0.89 | 0.03196 | 0.812 | 0.9 | 5 |
21 | 0.032 | 0.873 | 0.032 | 0.81 | 0.02846 | 0.723 | 0.711 | 3.2 |
22 | 0.028 | 0.711 | 0.028 | 0.71 | 0.02535 | 0.644 | 0.558 | 3.1 |
Shandong Zhengde Metal Manufacturing Co., Ltd. is a production and sales company integrating hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, section steel, steel pipes, steel wires, metal mesh, stainless steel, aluminum, copper and other metal products integrated large enterprises. Five production and sales bases have been formed in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan and Tai'an, with more than 100 production lines, 4 nationally recognized laboratories, 2 technical engineering centers, and 5 enterprise technology centers. Products are exported to more than 50 countries and regions such as North America, South America, Europe, Middle East region, Russia, Africa, North America, and other parts of the world.
Company Philosophy:
Quality first: production and inspection in strict accordance with production standards;
Price advantage: discounts based on real market prices;
Transaction security: There will be no loss of customer funds;
After-sales guarantee: the customer's problem is our problem;
Long-term cooperation: quality assurance, price advantage, sincere service can last for a long time.
If you encounter dishonest manufacturers during the procurement process, we can provide you with a professional legal team. We hope our cooperation is full of sunshine!
Welcome to the company for investigation and cooperation, and look forward to friendly cooperation with you!
